Section

7.2

7-20

A38E Work Platform

Illustrated Parts Breakdown

TRACTION MOTOR ASSEMBLY

ITEM PART NO. DESCRIPTION

QTY.

1 514274-001 BRUSH

1

2 514274-002 BOLT

1

3 514274-003 SPRING

1

4 514274-004 BRUSH BOX SUPPORT

1

5 514274-005 BRUSH BOX

1

6 514274-006 SHEATHING

1

514274-000

SERIAL BREAK: (SN:006282 - 006522)
