Snorkel A38E-sn006001+ - Manual (Page 74)

Schematics
Section
6-4 A38E Work Platform
6.1
A 38E ANSI Electric Kit Parts
Circuit Diagram: 512819 -003
DESCRIPTION PART No. QTY
PLATFORM CONTROL BOX 513433-003
Enclosure(cut-out) 512936-003 -
Joys ck 510471-000 1
Matrix Board 510472-000 1
Alarm 502588-000 1
Twist& Release E/stop c/w 1 N/C contact block 510524-000 1
Black Flush Push Bu on c/w 1 N/O contact block 510542-000 2
Toggle Switch, on-(on) IP65 510521-000 7
Boot 514132-000 6
Red LED 512934-000 1
Green LED 512935-000 6
Pla orm Control Box Overlay 512937-003 1
9-way Chassis Socket 513949-000 1
6-way Panel Plug 510154-000 1
9-way Panel Plug 510156-000 1
12-way Panel Plug 510157-000 2
Mate-N-Lock Socket Contact 510145-000 30
DIN Rail 512368-000 0.4
GROUND CONTROL PANEL 513434-001
Ground Control Panel 512939-001 1
Ground Control Panel Overlay 512940-000 1
Ezcal Display 3087803 1
Twist& Release E/stop c/w 1 N/C contact block 510524-000 1
3 posn. Stayput Key Switch (key removeable in any
posi on) c/w/2 N/O contact blocks 510526-000 1
Analogue Rocker 514131-000 1
Deadman Toggle Switch, on-(on) IP65 510521-000 4
Boot 514132-000 6
19-Way Cable Clamp Socket 513951-000 1
4-way Panel Plug 512366-000 1
Mate-N-Lock Socket Contact 510145-000 4
3 amp diode. 510150-000 2
External Components
12v Solenoid coil 505555-016 14
Alarm 502588-000 1
Alarm bracket 512684-000 1
Fuse 300Amp 067387-022 1
Fuse holder 501877-000 1
Contactor, 200Amp 12vdc SPDT 513550-000 1
GP400 512941-000 1
SEM600 512942-000 1
P600 512943-000 1
Trac on motors 512944-000 2
Eleva on Switch 058864-000 1
Horn 501868-001 1
Ferrite 510437-000 5
Cable Assemblies
A38E Wire Harness PG Trionics 513539-000 1
A38E Valve Cable 513540-001 1
A38E Addi onal Cable Kit 513541-000 1
A38E Power Cable Kit 513542-000 1
