Section
7.2
7-20 A38E Work Platform
Illustrated Parts Breakdown
REAR & FRONT WHEEL KIT
(NON MARKING)
SERIAL 1297 TO 004942
500494-000
REAR & FRONT WHEEL KIT
(NON MARKING)
SERIAL 004940-004943 TO CURRENT
ITEM PART NO. DESCRIPTION QTY.
1 057578-000 WHEEL NUT - M14 10
2 057668-001 REAR WHEEL TYRE & ASSY. 2
3 057666-000 WHEEL NUT - M16 10
4 057667-003 FRONT WHEEL TYRE & RIM ASSY. 2
ITEM PART NO. DESCRIPTION QTY.
1 057578-000 WHEEL NUT - M14 10
2 513429-000 REAR WHEEL TYRE & ASSY. (MAGNUM) 2
3 057666-000 WHEEL NUT - M16 10
4 513430-000 FRONT WHEEL TYRE & RIM ASSY. (MAGNUM) 2
