Illustrated parts breakdown – Snorkel A38E-sn006001+ User Manual
Page 86
Section
7.2
7-8
A38E Work Platform
Illustrated Parts Breakdown
BOOMS & POSTS ASSEMBLY
500201-000
ITEM PART NO. DESCRIPTION
QTY.
1
058412-000 A38E FIRST POST WELDMENT
1
2
512614-000 BALLAST ASSEMBLY CE
1
*
512614-001 BALLAST ASSEMBLY ANSI
1
3
058417-000 A38E TENSION BAR WELDMENT
2
4
058416-000 A38E SECOND POST WELDMENT
1
5
058413-000 A38E LOWER BOOM WELDMENT
1
6
058414-001 OUTER TELE BOOM WELDMENT
1
*
260297
WEAR PAD 1-3/4" -4 ACME THREAD
2
7
058415-001 INNER TELESCOPIC BOOM WELDMENT
1
8
058457-002 A38E HOSE CABLE COVER
1
9
500265-000 COVER FOR ENERGY CHAIN CHANNEL
1
*
057727-000 TWIST SCREW FASTENER
2
10 500266-000 ENERGY CHAIN SUPPORT CHANNEL
1
11 500468-000 ENERGY CHAIN - COMPLETE
1
*
500468-002 ENERGY CHAIN (1 UNIT OF 24)
24
*
500468-001 MOUNTING ELEMENTS
1
12 057975-000 INNER TELESCOPIC BOOM WEAR PAD
2
*
058510-016 M8 X 16 CSK
6
*
058510-025 M8 X 25 CSK
2
13 500275-001 OUTER TELESCOPIC BOOM WEAR PAD
2
*
058491-010 M6 X 10 HEX
8
*
500519-006 1/4" T4 WASHER
8
*
057975-300 6mm INSERTS
8
14 504504-000 A38E LOWER LIFT CYLINDER
1
15 504505-000 A38E UPPER LIFT CYLINDER
1
16 058734-000 A38E MASTER LEVELLING CYLINDER
1
17 058735-000 A38E SLAVE LEVELLING CYLINDER
1
18 058461-000 A38E TELESCOPIC CYLINDER
1
19 058056-000 PIN LOCK PLATE
16
056060-016 BOLT M10 X 16 mm
16
056021-010 SPRING WASHER 10 mm
16
20 058055-006 PIN-LOWER & UPPER BOOM TO FIRST
3
& SECOND POST
21 058054-001 PIN - TENSION BARS
4
22 058066-001 PIN - LIFT CYLINDER ROD END
1
23 058066-007 PIN - UPPER LIFT CYLINDER BODY END
1
24 058053-004 PIN - MASTER CYLINDER ROD END
1
25 058053-005 PIN - MASTER CYLINDER BODY END
1
26 058065-006 PIN - TELE CYLINDER BODY END
1
27 500254-000 PIN - TELE CYLINDER ROD END
1
28 058053-001 PIN - SLAVE CYLINDER BODY END
1
29 058065-005 PIN - SLAVE CYLINDER ROD END
1
30 058066-001 PIN - TELESCOPIC BOOM TO CAGE
1
31 057033-000 CIRCLIP 30mm
4
32 057047-000 BUSHING STRAIGHT 25mm
8
33 057054-000 BUSHING FLANGED 30mm
12
34 057046-000 BUSHING FLANGED 35mm
8
35 057034-000 CIRCLIP 25mm
4
36 501085-000 BOOM REST (BOLT ON)
1
SERIAL BREAK
2890 - 3144 : Part No: 058460-000
SERIAL BREAK
2890 - 3144 : Part No: 058462-000
3145 - Current : Part No: 504505-000
