Section
7.2
7-34 A38E Work Platform
Illustrated Parts Breakdown
TELESCOPIC CYLINDER ASSEMBLY
058461-000
NOTE: ITEMS 6 TO 9 INCLUSIVE, 12 & 14
FORM THE SEAL KIT FOR THE A38E
TELESCOPIC CYLINDER. THE PART
NUMBER FOR THIS SEAL KIT IS
500459-000
ITEM PART NO. DESCRIPTION QTY.
1 ─ CYLINDER BODY 1
2 058728-000 SINGLE OVERCENTRE VALVE 1
3 058714-000 SINGLE P.O. CHECK VALVE 1
4 ─ END CAP 1
5 ─ ROD AND END PIVOT 1
6 SEE NOTE U-RING ROD SEAL 1
7 SEE NOTE ROD SEAL 1
8 SEE NOTE WIPER 1
9 SEE NOTE O-RING 1
10 057048-000 GREASE NIPPLE
11 ─ SPACER 1
12 SEE NOTE PISTON O-RING 1
13 ─ PISTON HEAD 1
14 SEE NOTE PISTON SEAL 1
15 057121-000 PISTON LOCKNUT 1
16 501964-000 WASHER 1
