v A38E Work Platform
General Description & Machine Specifications.
Foreword
Introduction &
Specifications
1.0
Machine Preparation
2.0
Information on the preparation for use, shipment,
forklifting, transporting and storage.
Operation 3.0
Operating Instructions & Safety Rules.
Maintenance 4.0
Preventative Maintenance & Service Intervals.
Troubleshooting 5.0
Causes of and Solutions to typical problems.
Schematics
6.0
Schematics and Valve Block Diagram with
description and location of components.
Illustrated Parts
Breakdown
7.0
Complete parts lists with illustrations.
Introduction
HOW TO USE THIS MANUAL
This manual is divided into 7 Sections,
The right hand pages of each Section is marked with a black
section number printed at the top corner of each page which
can be used as a quick guide.
SPECIAL INFORMATION
Notes: Give helpful information.
All information contained in this manual is based on the
latest product information available at the time of printing.
We reserve the right to make changes at any time without
notice. No part of this publication may be reproduced,
stored in retrieval system, or transmitted, in any form by
any means, electronic, mechanical, photocopying,
recording, or otherwise, without prior written permission of
the publisher. This includes text, figures and tables.
WORKSHOP PROCEDURES
Detailed descriptions of standard workshop
procedures, safety principles and service operations
are not included. Please note that this manual does
contain warnings and cautions against some specific
service methods which could cause personal injury,
could damage a machine and make it unsafe.
Please understand that these warnings cannot cover
all conceivable ways in which service, whether or not
recommended by Snorkel, can be done, or the possible
hazardous consequences of each conceivable way,
nor could Snorkel investigate all ways. Anyone using
service procedures or tools, whether or not recom-
mended by Snorkel, must satisfy themselves
thoroughly that neither personal safety nor machine
safety will be
or
jeopardised.
Indicates a potentially hazardous situation which, if not avoided, could
result in severe injury or death.
W A R N I N G
Indicates an imminently hazardous situation which, if not avoided, will
result in severe injury or death.
D A N G E R
Indicates a potentially hazardous sit uation which, if not avoided, may
result in minor or moderate injury.
C A U T I O N
C A U T I O N
