Section

7.2

7-36

A38E Work Platform

Illustrated Parts Breakdown

STEERING CYLINDER ASSEMBLY

058463-000

NOTE:ITEMS 3, 5, 6 & 7 FORM THE SEAL KIT

FOR THE A38E STEERING CYLINDER.

THE PART NUMBER FOR THIS SEAL

KIT IS 500460-000

ITEM PART NO. DESCRIPTION

QTY.

1

─

CYLINDER BODY

1

2

─

CYLINDER ROD

1

3

SEE NOTE PISTON SEAL

1

4

─

END CAP

1

5

SEE NOTE WIPER

1

6

SEE NOTE ROD SEAL

1

7

SEE NOTE O-RING

1

8

057048-000 GREASE NIPPLE

3
