12. OPTIONS

12 - 6

P/N 0082168

D A N G E R

A “runaway” TB 60 can cause death or
serious injury. Disconnecting the disconnect-
plates will allow the TB 60 drive wheels to
turn freely. Before proceeding, be certain the
tow bar is installed and connected to a
towing vehicle that can safely control both
itself and the 20,700 pound (9,389 kg) TB 60.
Be certain the tow vehicle brakes are set.

1 5

1 6

1 7

7. Remove the two bolts (15) that hold each
drive-wheel disconnect-plate (16).

8. Turn each disconnect-plate (16) over so that
the nipple (17) points inward, then retighten the
bolts (15).

D A N G E R

At the end of the tow, before you disconnect
the TB 60 from the towing vehicle, turn the
disconnect-plates back over so the nipples
are out. This will prevent the TB 60 from
rolling when you disconnect it from the tow
vehicle.

9. Reverse the above procedure at the end of the
tow.
