12. OPTIONS
12 - 1 P/N 0082168
„
OPERATOR HORN
The operator HORN button is on the right side of
the platform-control box. For the HORN to work
the BATTERY switch must be ON and the
following switches, on the ground-control panel,
must be set as indicated:
SELECTOR SWITCH .......PLATFORM
EMERGENCY STOP........UP FOR RUN
MASTER ..........................ON
The operator HORN is used primarily to get the
attention of people on the ground when you are
working aloft.
„
PLATFORM WORK LIGHTS
The platform work lights are located on top the
platform guardrail. For the lights to work the
BATTERY switch must be ON and the following
switches, on the ground-control panel, must be
set as indicated:
SELECTOR SWITCH .......PLATFORM
EMERGENCY STOP........UP FOR RUN
MASTER ..........................ON
The toggle switch on the back of a light turns it
on.
If you want to change the direction a light points,
use two 1/2” box-end wrenches to loosen the
clamp immediately below the light, point the light
where you want it, then retighten the clamp.
C A U TIO N
Incandescent lights draw three amperes (35
watts) each. Halogen lights draw four amperes
(50 watts) each. If you work with the lights turned
on and the engine turned off, the battery(ies) can
get discharged to the point it will not start the
engine nor run the EMERGENCY POWER
hydraulic pump. If you cannot leave the engine
running while the lights are on, start and run the
engine at least 15 minutes in each hour.
„
DRIVING LIGHTS
C A U TIO N
Together the four lights draw seven amperes. If
you work with the lights turned on and the engine
turned off, the battery(ies) can get discharged to
the point it will not start the engine nor run the
EMERGENCY POWER hydraulic pump. If you
cannot leave the engine running while the lights
are on, start and run the engine at least 15
minutes in each hour.
Driving lights are for driving on dimly lit
construction sites, they are not for driving on
public thoroughfares. Two 30 watt headlights are
located on top of the front cowling, two 25 watt
blinking taillights are on the sides of the rear
cowlings. Each headlight has a toggle switch to
turn it on and off. Both blinking taillights are
controlled by a switch just in front of the right
taillight. For any of the lights to work both the
BATTERY switch and the MASTER switch must
be ON.
