10. DAILY INSPECTION & MAINTENANCE
10 - 10 P/N 0082168
25. Placards and decals
Look to see that all placards and decal are in place and legible. Replace any missing or illegible
placards or decals before placing the TB 60 into service for the daily work shift.
The OPTIONAL PLACARDS AND DECALS, listed below on this page, are only installed on machines
that have the corresponding options.
Placard and decal kits for the TB 60 are available from Snorkel dealers.
PLACARDS AND DECALS INSPECTION CHART
NO PART # DESCRIPTION REQ
1 0073298 Danger - Foam filled tires 2
2 0323896 Danger - electrocution hazard 5
3 0070420 Emergency bleed down 1
4 0070418 Snorkelift logo 4
5 0323897 Danger - you must not operate 1
6 0074209 Pre-start instruction 1
7 0090589 Platform capacity 500 lb 1
8 0323899 Danger - electrocution hazard 1
9 0070540 Yellow arrow 3
10 0070541 Blue arrow 3
11 0070901 Caution - serial number 1
12 0072530 Danger - electrocution hazard 1
13 0071425 Platform identification 1
14 0071927 Hydraulic oil 1
15 0082014 Platform control box top 1
16 0180846 Platform control box front 1
17 0073491 Safe operating information 1
18 0082176 TB-60 logo 2
19 0150448 Attach fall restraint device 1
20 0073668 Caution - do not use boom 1
21 0181654 Danger - inspect unit 1
22 0181655 Caution - move control handle
slowly 1
23 0072531 Danger - electrocution hazard 1
24 0190989 Danger - do not reach through
holes 1
25 0070921 125 volt 20 amp power 2
26 0074210 Danger - electrocution/tipping
hazard 1
27 0111735 Main system/run/throttle 1
28 0082003 Ground controls 1
29 0073043 Manual holder 1
30 0073224 Notice manual re-order 1
31 0072541 Danger - do not operate 1
32 0073492 Rotate while greasing 1
33 0073585 Made in USA 2
34 0181562 ANSI A92.5-1992 1
35 0073667 Inspect wire ropes 2
Additional decals found on Diesel machines
NO PART # DESCRIPTION REQ
60 0071926 Diesel fuel 1
Additional decals found on Gasoline machines
NO PART # DESCRIPTION REQ
70 0071925 Gasoline fuel 1
71 0151410 Danger - rotating engine parts 2
Additional decals found on 4x2 machines
NO PART # DESCRIPTION REQ
80 0072276 Lug nut torque 450-500 ft lb 2
81 0072277 Lug nut torque 200-225 ft lb 2
Additional decals found on 4x4 machines
NO PART # DESCRIPTION REQ
90 0072276 Lug nut torque 450-500 ft lb 4
OPTIONAL PLACARDS AND DECALS
NO PART # DESCRIPTION REQ
A 0081441 Caution - liquid withdrawal 1
B 0082064 Manifold heater instructions 1
C 0071269 Horn 1
D 0080650 Lift 4
E 0090492 Dual fuel switch 1
F 0090493 Dual fuel instructions 1
G 0071792 Warm-up switch 2
H 0071793 Hydraulic system warm-up
instructions 1
J 0072203 Towing instructions 2
K 0082160 Danger - do not exceed 1
L 0082164 Danger - do not ride... 1
M 0082203 Danger - crushing hazard 1
N 0181634 Engine block heater 1
P 0110492 Platform capacity 600 lb 1
R 0073085 Platform capacity 650 lb 1
