3. SPECIFICATIONS
3 - 1
P/N 0082168
The Snorkelift TB 60 is a boom-supported
elevating work-platform built to conform to the
following standards:
OSHA Paragraph 1910.67 Title 29, C.F.R.
Vehicle-Mounted Elevating and Rotating Work
Platforms - Labor.
OSHA Paragraph 1926.556 Title 29, C.F.R Aerial
Lifts - Construction.
ANSI Standard A92.5, Boom-Supported
Elevating Work Platforms.
CSA Standard CAN3-B354.4-M82, Boom-type
Elevating Work Platforms.
„
GENERAL SPECIFICATIONS
Working height (nominal) ...... 66 ft - 0 in (20.1 m)
Platform height (maximum) ... 60 ft - 0 in (18.3 m)
Platform reach (maximum) .... 50 ft - 0 in (15.2 m)
Length
(
booms down and retracted ) .. 30 ft - 10 in (9.4 m)
Width...................................... 8 ft - 0.5 in (2.5 m)
Height
(booms down and retraced) .... 8 ft - 9 in (2.7 m)
Wheelbase .............................. 10 ft - 0 in (3.0 m)
Ground clearance........................... 13 in (33 cm)
Weight (approximate) ......... 20,700 lbs (9,389 kg)
Ground pressure, max............... 64 psi (442 kPa)
Wheel load, max. single........10,600 lbs (4,808 kg)
Boom elevation .................+72°/-16° to horizontal
Gradeability.................................................. 25%
Travel speeds:
booms down and retracted .. 3.0 mph (4.8 km/hr)
booms up and/or extended.... 1 mph (1.6 km/hr)
Turning radius, inside................ 15 ft 5 in (4.7 m)
Tires......................... 15 x 19.5 in (38 X 50 cm), 12 ply
Electrical system .. 12 V dc (neg. chassis ground)
Environmental operating ranges:
ambient air temperature .............. 0°F to +110°F
................................................. (-18°C to +43°C)
wind speed (maximum gust
or continuous) ...................... 28 mph (45 km/hr)
Fuel tank capacity:
standard gasoline
or diesel ........................ 40 gal USA (151 liters)
optional LPG .................... 43.5 lbs USA (20 kg)
optional gasoline or diesel
(Used when LPG cylinder is mounted
inside the turntable, in front of the
gasoline or diesel tank.) ... 20 gal USA (76 liters)
Hydraulic oil tank capacity .. 26.1 gal USA (99 liters)
Maximum hydraulic oil temperature
(at tank) ....................................... 200°F (93°C)
Hydraulic oil system
capacity ........................ 35 gal USA (132 liters)
Hydraulic oil and grade
Above 10°F (-13°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M (ISO VG15)
Hydraulic system
maximum pressure ....... 2,500 psi (17,250 kPa)
Boom movement times
(complete range of movement):
Turntable Swing
CW or CCW (360°): ............... 85 - 95 seconds
Platform Rotation
CW or CCW (180°): ............... 16 - 20 seconds
Main Boom Elevation
UP:......................................... 40 - 45 seconds
DOWN: .................................. 40 - 45 seconds
Boom Extension
OUT: ...................................... 60 - 70 seconds
IN: .......................................... 50 - 60 seconds
„
PLATFORM SPECIFICATIONS
PLATFORM
SIZE
inches (cm)
Unrestricted rated work load (total weight of personnel,
tools, and materials that the platform is designed to carry
above its floor -- same as UNRESTRICTED PLATFORM
CAPACITY)
standard steel 30 x 60 (76 x 152)
Rated work load: 500 lbs (227 kg)
Rated number of occupants: 2 people
optional steel 30 x 92 (76 x 233)
Rated work load: 500 lbs (227 kg)
Rated number of occupants: 2 people
optional aluminum 30 x 60 (76 x 152)
Rated work load: 660 lbs (300 kg)
Rated number of occupants: 2 people
optional aluminum 30 x 92 (76 x 233)
Rated work load: 600 lbs (273 kg)
Rated number of occupants: 2 people
