7. OPERATION
7 - 6 P/N 0082168
IMPORTANT
Ground-control panel operation: You must
hold the GROUND OPERATION switch (6) up
when you use any of the platform-moving
switches (1 through 5) to move the platform. This
is a safety feature to prevent the platform from
moving if a single platform-moving switch is
accidentally pushed.
IMPORTANT
Platform-control box operation: You must be
stepping on the foot switch (7) when you use any
of the platform-moving switches
(1 through 5) to move the platform. Also, you
must be stepping on the foot switch to use either
the BOOM controller or the DRIVE controller.
The foot switch is a safety feature to prevent the
platform from moving if a single platform-moving
switch is accidentally pushed.
FOOT SWITCH
GROUND-CONTROL PANEL
PLATFORM-CONTROL BOX
