Installing Your Server in a Rack 45
5 Slide the bracket toward the rear post until the bracket’s flange aligns with the post, and use
two attachment screws to secure the bracket to the post.
6 Tighten the screw that secures the short-rack bracket to the cover.
7 Attach the second short-rack bracket to server’s cover and the rear post, as described in steps
3 through 6.
Place the Server in the Rack
Once you’ve attached the cover, you can put the server into the rack.
1 At the front of the rack, lift the server to the level of the enclosure’s cover and slide the
server into the cover.
Secure the bracket to the rear rack post
using two of the attachment screws provided.
After the cover has been firmly attached to the rack, tighten the two short screws completely.
Insert the server into the cover
and slide it all the way back.
