Your server at a glance—front panel, Your server at a glance—front panel 10 – Apple Xserve (Slot Load) User Manual
Page 10
10
Chapter 1
Your Server at a Glance—Front Panel
Securing
thumbscrews (2)
Drive module
status light
Drive module
activity light
Optical drive
System identifier
button/light
Enclosure lock
and status light
FireWire 400 port
Power button /light
Apple Drive Module bays (4)
Ethernet card
link light
System activity lights
Built-in Ethernet
link light
