Editing channel displays – AEM 30-6905 Universal Programmable EMS-4 User Manual
Page 89
Page 89 of 279 EMS-4 Install and Tuning Guide_Rev 1.6
Editing Channel Displays
Channel Display Toolbar Icon Function
Show or hide the icon toolbar
Quick insert new channel
Move selected channel row up or down within the display
window.
Removes currently selected channel from display.
Change display contents. Opens separate window below:
Add or subtract channels by selecting them in left column. Click OK to confirm. Tree view is
also available by clicking the Tree tab.
Configure channel properties. Allows changes to how data is presented in the channel
displays.
