Editing 2D Table Displays
A 2D table represents a function that equates one value to another. AEM EMS calibrations
contain many 2D tables. Examples include sensor calibration tables that equate voltage to
temperature, tables that define desired idle speed as a function of coolant temperature, etc.
2D table in Graph View mode
2D table in Table View mode
Table Display Toolbar Icon Function
Show or hide the icon toolbar
Close display
Reset all states. Resets all modification states within the table window.
