Confirmation
Use appropriate dashboard cleaning liquids (commercially available) to
clean the area where the double sided tape will be attached.
If the adherence of double sided tape is not enough, use commercial tap-
ping screws(4mm).
7 -5. Setting and checking of operations
Both the switch unit of ADVANCE Control Unit and the buttons on ZD are used
to set up and operate. In this manual, each operation is indicated as:
ADVANCE Control unit operation → CU OPR ZD operation → ZD OPR
1. Turn the ignition ON. Confirm DC SOURCE LED of ADVANCE Control unit
lights up.
⇒ Refer to manual of ADVANCE Control unit.
2. Confirm the opening mode is performed (and then STREET display mode is
displayed).
⇒ Refer to 8 -5. Opening mode, 8 -6-2. Real mode
3. Confirm short-circuit (SHORT) or disconnected (OPEN) errors are not dis-
played.
⇒ Refer to 8 -8. Error display
If an error is displayed
→ Turn the ignition off immediately, and then confirm the wiring of the
sensor and the sensor wire.
4. Set up the speed pulse, number of cylinders, and tachometer response in
the system setup mode.
⇒ Refer to 8 -2. System setup mode
5. Set up the items displayed and warning values.
⇒ Refer to 8 -3. Display setup mode, 8 -7. Warning setup mode
6. Confirm ZD functions properly.
Warning
Set up while the vehicle is stopped.
8 Operation 8 -1. State transition diagram
Defi-Link ADVANCE System is composed as following diagram:
Opening mode
IGN OFF
IGN ON
Real mode ( STREET / GAIGE1 / GAIGE2 / TIME ATTACK )
Brightness adjustment
CU OPR ZD OPR
Display function, etc.
ZD OPR
Warning display
Diff. press. display
Special display
Error display
Warm-up display
Alarm
Pause
Fast-forward・Single frame forward
Rewind・Single frame rewind
Real peak mode
Real peak reset mode
Record mode
Rec peak mode
Playback mode
Play peak mode
Tachometer response setting
Dimmer setting
Special display setting
Warm-up setting
Clock setting
System setup mode(S1)
Units setting
Speed pulses setting
Number of cylinders setting
REV BAR maximum scale value setting
Sequential indicator lighting pattern setting
Sequential indicator lighting step setting
Oil pressure warning limit setting
Warning buzzer setting
Display setup mode(S2)
REV BAR scale range setting
Display number setting
Display item change
Display zone size change
Warning setup mode
Warning output ON/OFF
Alarm setting
STREET
Trip reset
Display mode change
Display mode change
Display mode change
Display mode change
GAUGE1
GAUGE2
TIME ATTACK
Time attack measuring
Best score clearing
Ending mode
