2 Product Features
Interactive communication advanced system is implemented. ⿟
Up to 7 ADVANCE gauges and displays in all can be controlled. ⿟
Gauges can be controlled from distance with the included switch unit. The ⿟
illumination color is white.
By connecting ADVANCE ZD to the ADVANCE system, the illumination of
⿟
ADVANCE BF and CR gauges is controlled automatically.
Opening and ending modes can be selected from 2 variations.
⿟
The installation of additional gauges is easy. Just connect it to other gauge ⿟
and attach the sensor to ADVANCE Control Unit.
Self-diagnosis system turns on the warning display to indicate any wire dis-
⿟
connection, short circuit and serial communication errors.
Warning by buzzer sound when the warning display is on (buzzer sound
⿟
can be turned on / off).
Peak value and warning value during driving are stored. Driving data can be
⿟
stored and replayed up to 3 minutes.
Mounting kits are provided with gauges and displays.
⿟
With both fuel pressure and turbo sensors installed, differential pressure ⿟
can be monitored on the fuel pressure gauge or ADVANCE ZD.
3 List of Products
■ ADVANCE CR gauges Φ 52 series
Product name Product No.
Defi-Link ADVANCE Control Unit DF07703
Product name Display range White Dial Black Dial
Turbo2.0 -100kPa ～ +200kPa DF07801 DF07802
Turbo1.2 -100kPa ～ +120kPa DF07901 DF07902
In-Mani Press ※ -100kPa ～ +20kPa DF08001 DF08002
Oil Press 0 ～ 1000kPa DF08101 DF08102
Fuel Press 0 ～ 600kPa DF08201 DF08202
Oil Temp 50 ～ 150℃ DF08301 DF08302
Water Temp 20 ～ 120℃ DF08401 DF08402
Exhaust Temp 200 ～ 1100℃ DF08501 DF08502
