Warning

If any indication of the problem is found in the product, check to make sure

the product will operate as expected. Failure to do so can lead to serious ac-
cidents.

If any problem is found during using, setting or operating this product, use

the following table to confirm proper operation of the unit. If the opera-
tional problem is not found in the following table, contact the installation
personnel at the store where this product was purchased.

Condition

Possible Cause

Corrective Action

○ Does not operate.
○ Power is not sup-

plied.

○ DC Source LED of

the control unit
doesn't light.

○ Wiring of the power supply wire

is improper.

○ The fuse of the power supply

wire is blown out.

○ The locks of the solderless con-

nectors are not locked tightly.

○ Check wirings of +B, IGN,

GND as per instructions in
this manual.

○ Check wiring and replace

the fuse.

○ Check the lock of the solder-

less connectors.

○ DC Source LED of

the control unit is
blinking.

○ There is a wire short circuit or

disconnected wire somewhere.
Maybe there is something
wrong on gauge.

○ Reconfirm the wiring and

the gauge according to
operation manual. If any
defects are not found, please
ask the shop for inspection.

○ Warning LED on

gauge is blinking

○ There is a wire short circuit or

disconnected wire somewhere
on sensor or sensor wire. Maybe
there is something wrong be-
tween gauge and control unit.

○ Reconfirm the sensor and

sensor wire according to
operation manual. If any
defects are not found, please
ask the shop for inspection.

8 Troubleshooting

74
