5. Return the slide switch to

U

or

M

.

7 -6-2. Set the warning buzzer ON/OFF

By sliding the dip switch1 of the control unit, the warning buzzer sound is
turned ON/OFF. The switch operation sound cannot be canceled.

Please set while the ignition is off.
The setting of warning buzzer for ZD is controlled by ZD. Refer to ZD

manual.

7 -6-3. Change the illumination color

Illumination color for CR gauges can be selected from 2 colors. Illumination
color of BF and ZD can not be changed.

1. Set the slide switch to

L

.

2. If the

L

button is pressed, the gauge shifts to Setup mode.

3. Select the gauge by pressing

L

button.

4. When the

M

button and the

R

button are pressed at the

same time, the illumination color changes.

white dial: blue ⇔ amber red

black dial: white ⇔ amber red

factory default setting: white dial is blue, black dial is white

In case that CR gauges and ZDs are installed together and the dimmer set-

ting is AUTO, the illumination of CR gauges turned ON/OFF automatically
regardless ON/OFF of the illumination switch of vehicle. If the setting is
done in bright light, the illumination of CR gauges may be unlighted. Please
place a hand over the dim sensor of ZD or move vehicle to a dark place.

5. Return the slide switch to

U

or

M

.

7 -6-4. Offset adjustment of Turbo (2.0 and 1.2) and In-Mani Press

The needle pointer of turbo should indicate 0kPa when the ignition is on. But
in rare cases the needle pointer is not indicating exactly 0kPa. If this happens,
