Defi ADVANCE Control Unit (DF07703 Manufactured in and before January, 2012) - Manual (Page 10)

■ ADVANCE CR gauges Φ 60 series
■ ADVANCE BF gauges Φ 60 series
Product name Display range White Dial Black Dial
Turbo2.0 -100kPa ～ +200kPa DF08601 DF08602
Turbo1.2 -100kPa ～ +120kPa DF08701 DF08702
In-Mani Press ※ -100kPa ～ +20kPa DF08801 DF08802
Oil Press 0 ～ 1000kPa DF08901 DF08902
Fuel Press 0 ～ 600kPa DF09001 DF09002
Oil Temp 50 ～ 150℃ DF09101 DF09102
Water Temp 20 ～ 120℃ DF09201 DF09202
Exhaust Temp 200 ～ 1100℃ DF09301 DF09302
Tachometer 0 ～ 9000rpm DF09403 DF09404
Product name Display range
White
Model
Amber Red
Model
Blue
Model
Turbo2.0 -100kPa ～ +200kPa DF09901 DF09902 DF09903
Turbo1.2 -100kPa ～ +120kPa DF10001 DF10002 DF10003
In-Mani Press ※ -100kPa ～ +20kPa DF10101 DF10102 DF10103
Oil Press 0 ～ 1000kPa DF10201 DF10202 DF10203
Fuel Press 0 ～ 600kPa DF10301 DF10302 DF10303
Oil Temp 50 ～ 150℃ DF10401 DF10402 DF10403
Water Temp 20 ～ 120℃ DF10501 DF10502 DF10503
Exhaust Temp 200 ～ 1100℃ DF10601 DF10602 DF10603
Tachometer 0 ～ 9000rpm DF10704 DF10705 DF10706
This product is a required for ADVANCE gauges and displays. This product
alone does not operate. Please use this product with gauges or displays
listed above. As for installation and operation, please refer to the manual for
gauges and displays as well.
※ In-Mani Press is an abbreviation of Intake Manifold Pressure.
Product Name Product No.
Defi-Link Meter ADVANCE ZD DF09701
48
