7 -2. Opening mode / Ending mode

When the ignition is turned on, gauges and ZDs perform opening mode.
When the ignition is turned off, gauge and ZDs perform ending mode and
then the power supplies of the control unit, gauges, and ZDs are shut off.

Confirmation

Depending on vehicles, the ignition is not turned off immediately after the

key is turned off. In this case, ending mode doesn't start until the ignition is
turned off.

If the ignition is turned off during setting, the setting data will not be saved.
If the power wire is wired correctly, the DC Source LED lights in blue from

the beginning of opening mode. If it stays off or is blinking, turn the ignition
off and check the wiring.
⇒ Refer to 6 Installation.

7 -2-1. Change of Opening mode / Ending mode

Opening and ending modes can be selected from A type (simple) and B type
(special) by sliding the dip switch 2 on the control unit.

Both types consists of lighting/blinking of peak & warning LED, the dial illumi-
nation, and sequential indicators of ZD, besides pointer movement and digital
display on ZD. Try both types!

Please slide the switch when the ignition is off. The modes for all the con-

nected gauges and ZDs are changed at the same time.

It might be hard to see the dial illumination depending on outside light

level.

7 -3. Real Mode (slide switch position :

U

)

After the opening mode finishes, the gauge shifts to Real mode. The real-time
vehicle conditions are displayed during Real mode.

61
