7 Operation
In this instruction, there are two kinds of ways to press buttons, "press" and
"press long." For "press," press the button for less than 1 second. For "press
long," press the button for more than 1 second.
7 -1. Setting and checking of operations
1. Turn the ignition on and confirm the DC Source LED on the control unit is
lighted up.
⇒ Refer to 6 Installation.
2. Confirm that the opening mode is performed.
⇒ Refer to 7 -2. Opening mode / Ending mode.
3. Confirm that there is no error message of wire disconnection/short circuit
on the gauges and ZDs.
⇒ Refer to 7 -3-2. Error displays of wire disconnection, short circuit, and serial error.
If an error is displayed
→ Turn the ignition off immediately, and then confirm the wiring of the
sensor and the sensor wire.
4. If the tachometer is installed, please set the number of cylinders and the response.
If ZDs are installed as well, settings for tachometer need to be done in Sys-
tem Setup Mode of ZD. The settings of ZD are applied to other tachometers
connected to the ADVANCE System. Refer to ZD manual for setting. If you
don not install either ZD or tachometer, go to next step.
⇒ Refer to 7 -4. Setting number of cylinders mode and 7 -5. Setting
Tachometer response mode.
5. Set warning values for all the connected gauges and ZDs. And then select
illumination color for CR gauges. Warning values for gauges and ZDs are
set at the same time.
⇒ Refer to 7 -6-3. Change the illumination color.
6. Confirm gauges and ZDs function normally. Setting is finished by confirming
the operations.
Warning
Please set while the vehicle is stopped.
