Do not apply excessive force on switches/terminals. It may result in dam-

age to the product.

Do not use wires other than the provided wires.
Do not attach wires on the body of the vehicle or engine parts as this may

result in damage to the product.

Install wires away from ignition and also radio signal frequency interference

as this could cause the gauges to malfunction.

Please set it up so that the equipment such as the wireless machines and

cellular phones that emit electric waves should not touch the unit. It may
result in incorrect operation.

Do not place wires near the engine, exhaust pipe or turbine. It may result in

damage or fusion of wires.

Make sure the waterproof processing is done when diverging wires in the

engine compartment.

Do not lay the gauge face down due to oil leakage.

Angle "A" must be more than 90 degrees.

When installing the sensor, do not bend the wire near the sensor body.

Wear gloves to avoid burns when soldering and cuts when installing wires,

sharp edges of parts.

Do not expose the unit to moisture, dust or direct sunlight, or place product

directly in front of heat vents.

Install sensors away from hot or wet places.

When using sunshade, put sunshade between products and windshield to
avoid direct sun exposure .

Use the dried soft cloth for cleanup. Do not use the cleaner except for the

neutral detergent. It results in trouble.

Do not pull the wires out of connectors forcefully. The

connectors may be broken and the wires may be cut.
When pulling out the wires, press the lock firmly to unclip
the locks of connectors.

Do not install gauges, including this product, into the passenger side or

center of the dashboard. It doesn't meet vehicle safety standards.

A

Over 90°
