Defi ADVANCE Control Unit (DF07703 Manufactured in and before January, 2012) User Manual
Page 29

7 -6-1. Set the warning value
1. Set the slide switch to
L
2. If the
L
button is pressed, the gauge shifts to Setup mode.
3. Select the gauge by pressing
L
button.
Selected
Not selected
CR gauges
Warning LED: blinking
Illumination: bright
(while vehicle illumination is ON)
Warning LED: unlighted
Illumination: dark
(while vehicle illumination is ON)
BF gauges
Warning LED: blinking
Illumination: bright
Warning LED: unlighted
Illumination: dark
ZD
Highlighted
Not highlighted
In case that CR gauges and ZDs are installed together and the dimmer set-
ting is AUTO, the illumination of CR gauges turned ON/OFF automatically
regardless ON/OFF of the illumination switch of vehicle. If the setting is
done in bright light, the illumination of CR gauges may be unlighted. Please
place a hand over the dim sensor of ZD or move vehicle to a dark place.
The only selected gauges will be displayed in the following order.
Turbo・In-Mani Press→Tachometer→Oil Press
↑ ↓
Exhaust temp←Water Temp←Oil Temp←Fuel Press
4. When the
M
button is pressed, the warning value becomes lower,
and when the
R
button is pressed, the warning value becomes
higher for the selected gauge. If each button is pressed long, the setting
value changes quickly.
If turbo(2.0 or 1.2) and intake manifold gauge are installed together, the set-
ting value of turbo(2.0 or 1.2) becomes the setting value of intake manifold.
You cannot set the value separately for each gauge. When both turbo2.0
and turbo1.2 are connected, turbo2.0 has a priority over turbo1.2.
Do not connect more than one gauge of the same variety.
(Ex. You can NOT connect 2 turbo2.0 gauges together.)
67
