7 -8. Real Peak Reset mode (slide switch position :

U

)

The peak value of driving and idling data can be reset. Regarding oil pressure
and fuel pressure, both the maximum value and the minimum value are reset.

1. Set the slide switch to

U

2. If the

M

button is pressed, the gauge shifts to Real Peak mode. The

LED is lighted up during Real Peak mode.

3. If the

R

button is pressed during Real Peak mode, the LED

starts blinking and the peak value is reset. After a reset, the gauge returns to
Real mode.

7 -9. Record mode (slide switch position:

U

)

Driving data can be recorded up to 3 minutes.

1. Set the slide switch to

U

.

2. If the

L

button is pressed, the gauge shifts to Record mode and

start recording. The LED is blinking during Rec mode.

3. If the

L

button is pressed, the gauge finishes recording and re-

turns to Real mode. Also after 3 minutes have passed from recording, the
gauge returns to Real mode.

It is possible to turn off the illumination of gauges and to display the differen-
tial pressure during Rec mode.
⇒ Refer to 7 -3-3. Illumination and 7 -3-4. Differential Pressure Display.

7 -10. Rec Peak mode (slide switch position:

U

)

The peak values recorded while recording are displayed during Record mode.
The maximum and minimum values are displayed in order as for oil pressure
and fuel pressure. The peak value of fuel pressure is displayed even while dis-
playing the differential pressure.

70
