Configuring the ARN for Netboot and Directed Netboot
114200 Rev. A
A-3
Frame Relay Settings
-fr
Configures the router COM interface as a Frame Relay connection.
With this setting, use one of the following options to specify a DLCMI
setting: -annexd,
-
annexa, or -lmi.
-annexd
-annexa
-lmi
When one of these options is used with the -fr setting, it specifies a
DLCMI setting. Use the same setting as the network to which the
router’s Frame Relay interface is connected. The default setting for
Frame Relay is -annexd.
Internal Clocking Setting
-int_clk
Sets the serial interface to internal clocking at 1.25 MB/s. If you do not
specify this setting, the router defaults to external clocking.
IP Connector Setting
Specifies the IP connector you are configuring. Use the format
com<
port #>.
IP Address Settings
Specifies the IP address of the interface you set with
Provide this address in dotted decimal notation.
Specifies the IP subnet mask of the interface you set with
Provide this address in dotted decimal notation.
Specifies the IP address of the next-hop router. Provide this address
in dotted decimal notation. Specify this address only if there are
intermediate routers between the router and the BootP server.
Table A-1.
ifconfig Command Settings for a COM Interface
(continued)
Setting
Description
