Installing and Operating BayStack ARN Routers
D-2 114200 Rev. A
ARN Token Ring Base Model Safety Status
Table D-2 lists the safety status of interconnection points to the connection of
other equipment.
ARN Expansion Modules Safety Status
Order Numbers CV0004011, CV0004012, CV0004013, CV0004014,
CV0004015 are upgrade options that provide an additional synchronous interface.
These options can be installed in any ARN model.
Table D-3 lists the safety status of the interconnection point (COM3, COM4,
COM5) provided by Order Nos. CV0004011, CV0004012, CV0004013,
CV0004014, CV0004015 to the connection of other equipment.
Table D-2. Safety Status (Order Nos. CV1101001, CV1101002,
CV1101003, CV1101004, CV1101005)
Port Location Port Description Type of Circuit
MAU Token Ring SELV
Console V.28 SELV
Table D-3. Safety Status (Order Nos. CV0004011, CV0004012,
CV0004013, CV0004014, CV0004015)
Port Location Port Description Type of Circuit
COM3, COM4, and COM5 V.28, X.21, V.35 Telecommunications
network voltage (TNV) at
SELV levels
AUI Ethernet AUI SELV
10Base-T Ethernet 10Base-T SELV
MAU Token Ring SELV
J2 Host Port SELV
