Installing and Operating BayStack ARN Routers
3-4
114200 Rev. A
Ethernet LEDs
describes the base module Ethernet LEDs.
Token Ring LEDs
describes the base module token ring LEDs.
Table 3-2.
Base Module Ethernet LEDs
LED
Meaning
Tx
(Transmit)
Lights when the Ethernet interface transmits data.
Rx
(Receive)
Lights when the Ethernet interface receives data.
Cl
(Collision)
Lights when the Ethernet interface detects a collision.
Table 3-3.
Base Module Token Ring LEDs
LED
Meaning
RCVR
(Receiver)
Lights when the interface is connected to the network.
NSRT
(Insert)
Lights when you insert the ARN into the token ring network.
WFLT
(Wire Fault)
Lights when the token ring hardware detects a wire fault
condition.
