Installing and Operating BayStack ARN Routers
1-10 114200 Rev. A
The ARN also supports up to two of the following adapter modules:
• Single serial interface
• Single ISDN BRI S/T interface
• Single ISDN BRI U interface
• Single V.34 modem adapter interface
• Single 56/64K DSU/CSU interface
Connecting Communications Cables
Gather the communications equipment and cabling that you will attach to the
ARN. If you do not have the proper cables, contact your network administrator or
see the Cable Guide for Routers and BNX Platforms.
Connecting to an Ethernet Interface
You can connect an Ethernet cable to any ARN base or expansion module that
contains an Ethernet interface option. Each Ethernet interface option offers two
Ethernet interface types -- an AUI transceiver interface or a 10Base-T interface.
Note: Refer to Appendix C, later in this manual, for ARN cable interface
descriptions.
Note: You can use only one Ethernet interface on an ARN base or expansion
module at any time. For example, you can connect to either the AUI
transceiver interface or the 10Base-T interface on a base module, but you
cannot use both interfaces at the same time.
