Requirements for European Operation
114200 Rev. A D-5
Table D-5. V.35 Interface (Order No. 7220)
Bay Networks Termination Remote Termination
Pin Signal Pin Signal
38 VSD+ P Send Data A
36 VSD- S Send Data B
34 VRT+ V Receive Timing A
33 VRT- X Receive Timing B
32 VST+ Y Send Timing A
31 VST- AA Send Timing B
37 VRD+ R Receive Data A
35 VRD- T Receive Data B
6 Data Set Ready+ E Data Set Ready
8 Data Terminal Ready+ H Data Terminal Ready
4 Request to Send+ C Request to Send
5 Clear to Send+ D Clear to Send
40 VTT+ U Terminal Timing A
39 VTT- W Terminal Timing B
1 Frame Ground A Frame Ground
9 Data Carrier Detect+ F Data Carrier Detect
19 Signal Ground B Signal Ground
Local Wire Connections
Pin 19 > 20 > 23 > 7
Pin 41 > 42 > 43
Pin 13 > 28
Pin 14 > 29
