Installing the BayStack Advanced Remote Node
114200 Rev. A 1-27
Connecting the Power Cable
Complete these steps to connect the power cable:
1. Connect the power cable to the power connector on the ARN back panel
(Figure 1-18) .
Figure 1-18. Connecting the Power Cable
2. Connect the remote end of the power cable to a grounded outlet.
Danger: Be sure that the power switch is in the OFF (0) position before you
connect the power cable.
Note: For information about connecting a redundant power supply to the
ARN, refer to your redundant power supply documentation.
ARN0017A
Redundant power supply cable Power cable
Redundant Power
UL
UL
100-240~
1.2A
50-60Hz
