Page 37: Screws (8 places), Alternative bracket position (2 places)
Installing the BayStack Advanced Remote Node
114200 Rev. A
1-7
Figure 1-2.
Attaching Flange Brackets to Rack-Mount the ARN
2.
Align the holes in the shorter end of the flange bracket with the holes in
the front vertical supports of the rack
Screws
(8 places)
ARN0004A
BayStack
Advanced Remote Node
RLSD3
RLSD4
RLSD5
Run
Boot
Fail
Pwr
RPS
Fan
Base
Adapter1
Adapter2
Expansion
DCM
PCMCIA
DD
B1
B2
RLSD
1
2
ISDN BRI
withNT1
Tx
Rx
Cl
Alternative
bracket
position
(2 places)
