Installing and Operating BayStack ARN Routers
1-6 114200 Rev. A
Rack-Mounting the ARN
For this procedure, you need
• Four #10 cagenut screws and washers (shipped with the ARN)
• Two flange brackets and eight #6 flathead screws (shipped with the ARN)
• A Phillips screwdriver
• An electronic enclosure rack
To rack-mount the ARN:
1. Attach a flange bracket to both sides of the ARN.
On each side of the chassis:
a. Align the holes in the longer end of the flange bracket with the
mounting holes near the front panel of the ARN (
Figure 1-2 ).
b. Insert a #6 flathead screw through each hole and into the ARN.
c. Tighten the four screws with a Phillips screwdriver.
Note: If the rack does not have threaded rail holes, you must supply and attach
four cagenuts.
