1. FRAME / DRIVE UNIT
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 UL9311001 1 MAIN MOTOR ASSY
2 087320616 4 TAPTITE, CUP S M3X6
3 LJ4069001 1 SOLENOID ASSY
4 000300415 1 SCREW, BIND M3X4
5 LJ4432001 1 TAPE 32X12
6 UL8984001 1 LINK
7 LJ4745001 1 FAN MOTOR UNIT
8 UL9099001 1 TONER EMPTY PCB UNIT (LIGHT EMISSION) B512038
9 UK4405001 1 PANEL PCB ASSY B512048
10 087320616 3 TAPTITE, CUP S M3X6
11 UL8507001 4 RUBBER FOOT
12 UL9104001 1 TONER EMPTY PCB UNIT (LIGHT RECEPTION) B512037
13 087320616 1 TAPTITE, CUP S M3X6
14 LJ8031001 1 LT RELAY PCB ASSY, HL-1250/1270N B512060
15 087320616 1 TAPTITE, CUP S M3X6
16 LE1169001 1 USB GROUND PLATE, HL-1270
17 UL8970001 1 SOLENOID RELEASE SPRING 30/99
18 LJ5591001 1 PLANET GEAR ASSY (SP)
19 UL8985001 1 GEAR 59
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-010
T/I NO. PR99165 / PR2000014 / PR2000073 / PR2000132 / PR2000152 / PR2001023
2. LASER UNIT
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ4157001 1 LASER UNIT (SP) (B512033)
2 087321615 3 TAPTITE, CUP S M3X16
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-020
