CHAPTER 4 DISASSEMBLY AND RE-ASSEMBLY
4-30A
!
CAUTION:
Be sure to attach the film to the AC inlet ASSY in the following cases referring to the figure
below;
•
If the film is not attached to the AC inlet on the printer you are servicing.
•
If the film is damaged, or the adhesive is weak.
Fig. 4-55a
PR99188
AC inlet ASSY
Film
