Get started
Model number: Nokia E51-1.
Hereinafter referred to as Nokia E51.
Insert the SIM card and battery
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider or other vendor.
1. With the back of the device facing you, press the release button (1) and
slide the back cover off (2).
2. If the battery is
inserted, lift the
battery in the
direction of the
arrow to
remove it.
3. Insert the SIM
card. Make sure
that the
contact area on
the card is
facing the
connectors on
the device and
that the
bevelled corner
is facing the
top of the device.
4. Insert the
battery. Align
the contacts of
the battery
with the
corresponding
connectors on
the battery
compartment
and insert in the direction of the arrow.
5. Slide the back
cover back to
place.
Charge the battery
1. Connect a compatible charger to a wall outlet.
2. Connect the
power cord to
the device. If
the battery is
completely
discharged, it
may take a
while before
the charging indicator starts scrolling.
3. When the battery is fully charged, disconnect the charger from the device,
then from the wall outlet.
Your battery has been precharged at the factory, but the charging levels may
vary. To reach the full operation time, charge the battery until it has been
fully charged according to the battery level indicator.
Tip: If you have old compatible Nokia chargers, you can use them with
the Nokia E51 by attaching the CA-44 charger adapter to the old
charger. The adapter is available as a separate enhancement.
Keys and parts
1 — Earpiece
2 — Power key
3 — Volume up key
4 — Mute key. Press the key to mute the microphone during a call.
5 — Volume down key
6 — Navi™ scroll key. Press the scroll key to enter a selection, to scroll left,
right, up, and down on the display.
7 — Selection key. Press the selection key to perform the function shown
above it on the display.
8 — End key. Press the end key to reject a call, end active calls and held calls,
and with a long keypress, end data connections.
9 — Backspace key. Press the key to delete items.
10 — Shift key. When writing text, press and hold the key and select the text
with the scroll key. Press this key for a few seconds to toggle between the
Silent and General profiles.
11 — Press the key for a few seconds to switch on Bluetooth connectivity.
When writing text, press the key and select More symbols to access special
characters.
12 — Call key
13 — Selection key
14 — Infrared port
15 — Voice key.
16 — Notification light and light sensor
17 — Microphone
18 — Headset connector
19 — Wrist strap hole
20 — Mini-USB port
21 — Charger connector
1 — Home key
2 — Contacts key
3 — E-mail key
4 — Calendar key
Connect the headset
Warning: When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can endanger your
safety.
Connect the compatible headset to the headset connector of your device.
