Select WLAN security settings > WEP key settings and from the following:
• WEP encryption — Select the desired WEP encryption key length.
• WEP key format — Select whether you want to enter the WEP key data
in ASCII or Hexadecimal format.
• WEP key — Enter the WEP key data.
802.1x security settings
Select 802.1x as the WLAN security mode.
802.1x authenticates and authorises devices to access a wireless network,
and prevents access if the authorisation process fails.
Select
WLAN security settings and from the following:
• WPA/WPA2 — Select EAP (Extensible Authentication Protocol) or Pre-
shared key (a secret key used for device identification).
• EAP plug-in settings — If you selected WPA/WPA2 > EAP , select which
EAP plug-ins defined in your device to use with the access point.
• Pre-shared key — If you selected WPA/WPA2 > Pre-shared key , enter
the shared private key that identifies your device to the WLAN to which
you connect.
WPA security settings
Select WPA/WPA2 as the WLAN security mode.
Select WLAN security settings and from the following:
• WPA/WPA2 — Select EAP (Extensible Authentication Protocol) or Pre-
shared key (a secret key used for device identification).
• EAP plug-in settings — If you select WPA/WPA2 > EAP , select which
EAP plug-ins defined in your device to use with the access point.
• Pre-shared key — If you select WPA/WPA2 > Pre-shared key , enter
the shared private key that identifies your device to the WLAN to which
you connect.
• WPA2 only mode — To allow both TKIP and AES (Advanced Encryption
Standard) encryption, select Off . To allow AES only, select On
Wireless LAN plugins
Select Menu > Tools > Settings > Connection > Access points .
The EAP (extensible authentication protocol) plug-ins are used in wireless
networks to authenticate wireless devices and authentication servers, and
the different EAP plug-ins make possible the use of various EAP methods
(network service).
You can view the EAP plug-ins currently installed in your device (network
service).
EAP plug-ins
1. To define the EAP plug-in settings, select Options > New access
point and define an access point that uses WLAN as a data bearer.
2. Select 802.1x or WPA/WPA2 as the security mode.
3. Select WLAN security settings > WPA/WPA2 > EAP > EAP plug-in
settings .
Use EAP plug-ins
To use an EAP plug-in when you connect to a WLAN using the access point,
select the desired plug-in and Options > Enable . The EAP plug-ins enabled
for use with this access point have a check mark next to them. To not use a
plug-in, select Options > Disable .
To edit the EAP plug-in settings, select Options > Edit .
To change the priority of the EAP plug-in settings, select Options > Raise
priority to attempt to use the plug-in before other plug-ins when connecting
to the network with the access point, or Options > Lower priority to use
this plug-in for network authentication after attempting to use other plug-
ins.
See the device help for more information on EAP plugins.
Session initiation protocol (SIP) settings
Select Menu > Tools > Settings > Connection > SIP settings .
Session initiation protocols (SIP) are used for creating, modifying, and
terminating certain types of communication sessions with one or more
participants (network service). Typical communication sessions are video
sharing and net calls. SIP profiles include settings for these sessions. The SIP
profile used by default for a communication session is underlined.
To create a SIP profile, select
Options > New SIP profile > Use default
profile or Use existing profile .
To select the SIP profile you want to use by default for communication
sessions, select Options > Default profile .
Edit SIP profiles
Select Options > Edit , and select from the following:
• Profile name — Enter a name for the SIP profile.
• Service profile — Select IETF or Nokia 3GPP .
• Default access point — Select the access point to use for the internet
connection.
• Public user name — Enter your user name received from your service
provider.
• Use compression — Select if compression is used.
• Registration — Select the registration mode.
• Use security — Select if security negotiation is used.
• Proxy server — Enter the proxy server settings for this SIP profile.
• Registrar server — Enter the registration server settings for this SIP
profile.
Edit SIP proxy servers
Select Options > New SIP profile or Edit > Proxy server .
Proxy servers are intermediate servers between a browsing service and its
users used by some service providers. These servers may provide additional
security and speed up access to the service.
Select from the following:
•
Proxy server address — Enter the host name or IP address of the proxy
server in use.
• Realm — Enter the proxy server realm.
• User name and Password — Enter your user name and password for the
proxy server.
• Allow loose routing — Select if loose routing is allowed.
• Transport type — Select UDP , Auto , or TCP .
• Port — Enter the port number of the proxy server.
Edit registration servers
Select Options > New SIP profile or Edit > Registrar server .
Select from the following:
•
Registrar server address — Enter the host name or IP address of the
registrar server in use.
• Realm — Enter the registrar server realm.
• User name and Password — Enter your user name and password for the
registrar server.
• Transport type — Select UDP , Auto , or TCP .
• Port — Enter the port number of the registrar server.
Net call settings
Select Menu > Tools > Settings > Connection > Internet tel. .
To create a new net call profile, select Options > New profile .
To edit an existing profile, select Options > Edit .
Configuration settings
Select Menu > Tools > Settings > Connection > Configurations .
You can receive messages from your service provider or company
information management containing configuration settings for trusted
servers. These settings are automatically saved in Configurations . You may
receive configuration settings for access points, multimedia, or e-mail
services, and IM or synchronisation settings from trusted servers.
To delete configurations for a trusted server, select
Options > Delete . The
configuration settings for other applications provided by this server are also
deleted.
Restrict packet data
Select Menu > Tools > Settings > Connection > APN control .
With the access point control service, you can restrict packet data
connections from your device to certain access points only. Your SIM card
may not support the access point control service. Contact your service
provider for more information.
To restrict the packet data connections from your device, select
Options >
Activate restrictions . You need your PIN2 code to activate and deactivate
access point control or to edit the packet data access points on the control
list.
To add access points that can be used for packet data connections to the
control list, select Options > Add name manually . To enable connections
to an operator-provided access point, create an empty access point.
To remove access points from the list, select
Options > Remove .
Application settings
Select Menu > Tools > Settings > Applications .
Select an application from the list to adjust its settings.
