136
Ap
pe
nd
ix
NAVI
/A
V Speed pulse wire is not connected.
Please be sure to connect the system
to the speed pulse wire. Accuracy is
not fully ensured without speed
pulse.
The speed signal input (pink lead
wire) of the power cable is not con-
nected.
To operate with 3D hybrid mode, con-
nect the speed signal input (pink
lead wire) of the power cable cor-
rectly.
Although it can be operated with
Simple hybrid mode without con-
necting the speed signal input, the
precision of the positioning will be
less accurate.
Vibration is detected. Please turn
system power off and check the
installation. After checking, please
re-boot the system and press “OK”.
The navigation system is installed in
a place where it may be affected by a
large vibration.
Re-install the Hide-away unit in a
place where the unit will not be
affected by vibration.
Direction of G sensor is not correct.
Please turn system power off and
check the installation. After check-
ing, please re-boot the system and
press “OK”.
Direction of G sensor is set incor-
rectly.
See the “Installation Manual” and set
the direction of the Hide-away unit
correctly.
Gyro Sensor is not working properly.
Please consult your dealer or Pioneer
service centre.
Abnormal output of Gyrosensor is
detected.
Note down the error code shown on
the screen; turn off the power, and
then contact your nearest Pioneer
service facility.
This function is not available now. The screen cannot be displayed with
Vehicle Dynamics Display.
Because the sensor has not been
taught so the sensor information
cannot be acquired.
If the sensor learning status reaches
the Sensor Initialising status or
more, the system is ready to be used.
System detected that the vertical
angle of the installation has been
changed. Learning status for Gyro
Sensor has been initialised.
If the mounting angle of the Hide-
away unit has been changed.
The system initialises the sensor in
order to operate it with the maximum
performance and automatically
starts re-learning.
System detected that the vertical
angle of the installation exceeds the
permission level. Please install the
navigation unit correctly.
The navigation system is installed
with an extreme angle exceeding the
limitation of the installation angle.
Confirm the installation angle. (The
navigation system must be installed
within +30 degrees to
–
30 degrees
of the horizontal, or within five
degrees of your vehicle’s direction of
travel.)
Route calculation was not possible. Route calculation has failed because
of malfunction of map data, software,
hardware, or disc.
• Change the destination.
• Clean the disc.
• Consult the Pioneer Local dealer if
this message persists.
Route calculation was not possible
because the destination is too far.
The destination is too far. • Set a destination closer to the start-
ing point.
• Set one or more way points.
Route calculation was not possible
because the destination is too near.
The destination or way point(s) are
too close.
Set a destination [and way point(s)]
farther from the starting point.
Route calculation was not possible
due to traffic regulations.
• The destination or way point(s) are
in a Control Traffic Zone (CTR) and
the route calculation is hampered.
• Your vehicle is currently in a Con-
trol Traffic Zone (CTR) and the
route calculation is hampered.
• Set a destination and way point(s)
outside the CTR if you know where
the restricted area is.
• Try the destination or way point(s)
away from the currently set points
to some extent.
• Drive your vehicle to an unre-
stricted area and reset the destina-
tion and way point(s).
Route calculation was not possible
because no guidance can be pro-
vided around the destination or the
starting point.
The destination, way point(s), or
starting point are in an area where no
road exists (e.g. a mountain) and the
route calculation is impossible.
• Set a destination and way point(s)
on roads.
• Reset the destination after you
drive the vehicle to any road.
Message When What to do
