22
2.7 Setting up the Stacker
2.7 Setting up the Stacker
The document set on the hopper, once scanned, will be ejected onto the stacker.
The Stacker table is horizontal, as a default, for aligning the bottom edge of the ejected documents, You
can tilled the Stacker table forward for aligning the leading edge of the ejected documents also.
Set up the Stacker by adjusting the Stacker extension, Stopper, Side Guides and Stacker's inclination.
■ Stacking the document
1. Pull out the stacker extension in accordance with document length.
ATTENTION
• Do not use the stopper to pull out the stacker extension. It may be dam-
aged.
• Be sure to extend the stopper longer than the document.
HINT
For short documents, use the small stopper.
Send to
Scan
Power Th ickness
Hopper H eight
Function
Thick
Thin
Stopper
Stacker extension
Small Stopper
