157
7.4 Hole-punching Prohibited Areas
7
DOCUMENT SPECIFICA
TIONS
7.4 Hole-punching Prohibited Areas
Punched holes in the shaded areas may cause errors.
For job separation sheet requirements, refer to
“7.7 Job Separation Sheet” on page 161 .
HINT
If there are any holes in the 35mm wide central column, you can set the doc-
ument a bit to the left or right to avoid detecting error.
F
eed
ing
Di
rect
ion
35
Center line
㧔Unit : mm㧕
15
Reference Point
Front Side
Leading edge
Bottom edge
