26 DS692DB2
CDB8422
Switch S4 controls the data format options for both serial output ports, see Table 4 for switch configurations.
For SDOUT2, the output resolution will be equal to the resolution of the incoming receiver data. The excep-
tion is the case where right-justified mode is selected and the receiver input word-length is an odd number
of bits. In this case, the SDOUT2 word-length will be zero-stuffed to be 1 bit longer than the receiver input
word-length (example: a 19-bit receiver input word will result in an 20-bit right-justified serial format).
Note: The CS8406 does not support Right-Justified 20-bit resolution in hardware mode.
SAOF[3:0] SDOUT1 SDOUT2
0000 I²S 24-bit
I²S 0001 I²S 20-bit
0010 I²S 16-bit
0011 Left-Justified 24-bit
Left-Justified 0100 Left-Justified 20-bit
0101 Left-Justified 16-bit
0110 Right-Justified 24-bit
(Master Mode only)
Right-Justified
(Master Mode only)
0111 Right-Justified 20-bit
(Master Mode only)
1000 Right-Justified 16-bit
(Master Mode only)
1001 TDM Mode 24-bit
I²S 1010 TDM Mode 20-bit
1011 TDM Mode 16-bit
1100
Reserved Reserved
1101
1110
1111
Table 4. S4 Settings
