CapturePlus II
20 DS789UM2
– Variance: The variance statistical measurement is in units of volts
2
or LSBs
2
(least significant bits).
The variance statistical measurement units are set by the Magnitude Display button in the General
Configuration menu.
– Minimum: The minimum statistical measurement is in units of volts or LSBs (least significant bits).
The minimum statistical measurement units are set by the Magnitude Display button in the General
Configuration menu.
– Maximum: The maximum statistical measurement is in units of volts or LSBs (least significant bits).
The maximum statistical measurement units are set by the Magnitude Display button in the General
Configuration menu.
4.2.8 About Tab
The About panel displays copyright information for the Cirrus Logic CapturePlus II data acquisition soft-
ware. Select the About tab to display this panel. Click on any other tab to exit this panel.
