98 DS880F4
CS4207
6.11.3 Mic In 1/Line In 2 Pin Capabilities
Get Parameter Command Format:
Response Format:
15:8 Read Only 00h
VREF Control (VREFC): VREF generation is
not supported by this widget.
7 Read Only 0b
HDMI Capable (HDMIC): This widget is not
capable of supporting HDMI.
6 Read Only 0b
Balanced I/O Pins (BIOP): This widget does not
have balanced I/O pins.
5 Read Only 1b
Input Capable (INC): Widget is input capable.
4 Read Only 0b
Output Capable (OUTC): Widget is not output
capable.
3 Read Only 0b
Headphone Drive Capable (HDC): Widget is
not capable of driving headphones directly.
2 Read Only 1b
Presence Detect Capable (PDC): This bit is ‘1’
to indicate that the widget is capable of perform-
ing presence detect to determine whether there
is anything plugged in.
1 Read Only 0b
Trigger Required (TR): Trigger is not required
for an impedance measurement.
0 Read Only 0b
Impedance Sense Capable (ISC): This bit is ‘0’
to indicate that the widget does not support
impedance sense on the attached peripheral.
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 0Dh Verb ID = F00h Parameter ID = 0Ch
Bits Type Default Description
31:17 Read Only 0 Reserved
16 Read Only 0b
EAPD Capable (EAPDC): This widget does not
support EAPD.
15:8 Read Only 17h
VREF Control (VREFC): VREF generation is
supported by this widget. Ground/80%/50%/Hi-Z
are supported. 100% is not supported.
7 Read Only 0b
HDMI Capable (HDMIC): This widget is not
capable of supporting HDMI.
6 Read Only 1b
Balanced I/O Pins (BIOP): This widget has bal-
anced I/O pins.
5 Read Only 1b
Input Capable (INC): Widget is input capable.
4 Read Only 0b
Output Capable (OUTC): Widget is not output
capable.
3 Read Only 0b
Headphone Drive Capable (HDC): Widget is
not capable of driving headphones directly.
2 Read Only 1b
Presence Detect Capable (PDC): This bit is ‘1’
to indicate that the widget is capable of perform-
ing presence detect to determine whether there
is anything plugged in.
1 Read Only 0b
Trigger Required (TR): Trigger is not required
for an impedance measurement.
Bits Type Default Description
