78 DS880F4
CS4207
6.8 Headphone Pin Widget (Node ID = 09h)
6.8.1 Audio Widget Capabilities
Get Parameter Command Format:
Response Format:
6.8.2 Pin Capabilities
Get Parameter Command Format:
Response Format:
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 09h Verb ID = F00h Parameter ID = 09h
Bits Type Default Description
31:24 Read Only 00h Reserved
23:20 Read Only 4h
Type (TYP): Pin Complex Widget
19:16 Read Only 1h
Delay (DLY): Number of sample delays through
the widget.
15:12 Read Only 0h Reserved
11 Read Only 0b
L-R Swap (LRS): This widget is not capable of
swapping the left and right channels.
10 Read Only 1b
Power Control (PC): Power State control is sup-
ported on this widget.
9 Read Only 0b
Digital (DIG): Widget is not a digital widget.
8 Read Only 1b
Connection List (CL): A connection list is
present on this widget.
7 Read Only 1b
Unsolicited Capable (UC): Unsolicited
Response is supported on this widget.
6 Read Only 0b
Processing Widget (PW): This widget does not
contain “Processing Controls” parameters.
5 Read Only 0b
Stripe (STRP): Striping is not supported.
4 Read Only 0b
Format Override (FO): This widget does not
contain format information.
3 Read Only 0b
Amplifier Parameter Override (APO): This wid-
get does not contain amplifier parameters.
2 Read Only 0b
Output Amplifier Present (OAP): Output ampli-
fier is not present for this widget.
1 Read Only 0b
Input Amplifier Present (IAP): Input amplifier is
not present for this widget.
0 Read Only 1b
Stereo (ST): A 1 indicates a stereo widget.
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 09h Verb ID = F00h Parameter ID = 0Ch
Bits Type Default Description
31:17 Read Only 0 Reserved
16 Read Only 0b
EAPD Capable (EAPDC): This widget does not
support EAPD.
