Reporting of ClkStopOk when stopping of the clock would be permitted. The CLKSTOP is a static ca-
pability with ClkStopOk a dynamic reporting. The setting the capability CLKSTOP to one (1) and not al-
lowing the clock to stop by not reporting ClkStopOk is not permissible. Unless there is a condition or
dependency that the host software cannot be made aware of, that would prohibit stopping the clock, the
ClkStopOk shall be reported as set (1). It is expected that host software will poll the ClkStopOk before
stopping the clock if the CLKSTOP is reported at one (1).
6.3.7
GPIO Capabilities
Get Parameter Command Format:
Response Format:
Bits [31:28]
Bits [27:20]
Bits [19:8]
Bits [7:0]
CAd = X
Node ID = 01h
Verb ID = F00h
Parameter ID = 11h
Bits
Type
Default
Description
31
Read Only
0b
GPIOWake: Does not support wake functionality.
30
Read Only
0b
GPIOUnsol: Does not support UR functionality.
29:24
Read Only
0h
Reserved
23:16
Read Only
0h
NumGPIs: No dedicated GPI pins.
15:8
Read Only
0h
NumGPOs: No dedicated GPO pins.
7:0
Read Only
4h
NumGPIOs: AFG supports 4 GPIO pins.
