44 DS880F4
CS4207
Response Format:
6.3.13 Implementation Identification
This field provides the Board Implementation ID and Assembly ID of the functional group to software. It is a
Read/Write-Once register; BIOS writes to this field to configure the Board Implementation ID and Assembly ID during
the boot process.
Get Parameter Command Format:
Set Parameter Command Format:
Response Format:
6.3.14 Function Reset
Function Reset is an “Execute” verb. There is no physical register associated with the Function Reset.
See
“Function Group Reset” section on page 25 for more details.
Set Parameter Command Format:
Bits Type Default Description
31:8 Read Only 000000h Reserved
7:4 Read Only 0h
GPIO[7:4] Sticky Mask: Not Supported.
3:0 Read/Write 0h
GPIO[3:0] Sticky Mask: Defines GPIO Input
Type (0 = Non-Sticky, 1 = Sticky) when a GPIO
pin is configured as an input. GPIO inputs config-
ured as Sticky are cleared by writing a 0 to the
corresponding bit of the GPIO Data Control
The default value for these bits (0h) is all pins
Non-Sticky. Non implemented GPIO pins always
return 0’s. Sticky is defined as Positive-Edge
sensitive, Non-Sticky as Level sensitive.
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 01h Verb ID = F20h Payload = 00h
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 01h Verb ID = 720h Payload = xxh (IID bits [7:0])
CAd = X Node ID = 01h Verb ID = 721h Payload = xxh (IID bits [15:8])
CAd = X Node ID = 01h Verb ID = 722h Payload = xxh (IID bits [23:16])
CAd = X Node ID = 01h Verb ID = 723h Payload = xxh (IID bits [31:24])
Bits Type Default Description
31:16 Read/Write Once 1013h
Board Manufacturer Identification (BMID):
Contains the PCI Vendor ID of the board manu-
facturer. Preset to Cirrus Logic’s PCI Vendor ID.
15:8 Read/Write Once 42h
Board SKU (BSKU): Assigned by the board
manufacturer to identify the specific board
design. Preset to 42h for Cirrus Logic codecs.
7:0 Read/Write Once 07h
Assembly ID (AssyID): Uniquely identifies the
specific board assembly. Preset to 07h for the
CS4207.
Bits [31:28] Bits [27:20] Bits [19:8] Bits [7:0]
CAd = X Node ID = 01h Verb ID = 7FFh Payload = 00h
