DS880F4 147
CS4207
11.ORDERING INFORMATION
12.REFERENCES
1. Intel Corporation,
High Definition Audio Specification, Revision 1.0, April 15, 2004.
http://download.intel.com/standards/hdaudio/pdf/HDAudio_03.pdf
2. Intel Corporation,
HDA006-A: Clarification to Sub-system Identification reporting, December 8, 2005.
http://www.intel.com/standards/hdaudio/pdf/hda006-a.pdf
3. Intel Corporation, HDA022-A:
Clarification of Channel count specification language, December 8, 2005
http://www.intel.com/standards/hdaudio/pdf/hda022-a.pdf
4. Intel Corporation,
HDA024-A: Addition of Dual Voltage Interface Support, November 15, 2006.
http://download.intel.com/standards/hdaudio/pdf/hda024-a.pdf
5. Intel Corporation,
HDA015-B: Low Power Capabilities Clarifications and Enhancements, June 6, 2009.
http://download.intel.com/design/chipsets/hdaudio/HDA015-B.pdf
6. Cirrus Logic,
AN48: Design Notes for a 2-Pole Filter with Differential Input, March 2003.
http://www.cirrus.com/en/pubs/appNote/AN048Rev2.pdf
13.REVISION HISTORY
Product Description Package Pb-Free Grade Temp Range Container Order #
CS4207
Low Power, 4-In/6-Out
HD Audio Codec with
Headphone Amp
48L-QFN Yes Commercial -40°C to +85°C
Tray CS4207-CNZ
Tape & Reel CS4207-CNZR
CS4207
Low Power, 4-In/6-Out
HD Audio Codec with
Headphone Amp
48L-QFN Yes Automotive -40°C to +105°C
Tray CS4207-DNZ
Tape & Reel CS4207-DNZR
CDB4207 CS4207 Evaluation Board - - - - CDB4207
Revision Changes
F1 • Production Release
F2
• Added “Digital Microphone Interface Characteristics” on page 22
• Updated “Implementation Identification” on page 44 as per HDA006-A
• Updated ADC1 SZCMode in “ADC Configuration (CIR = 0002h)” on page 131
• Updated DAC1 SZCMode in “DAC Configuration (CIR = 0003h)” on page 134
• Added “Analog Inputs” on page 139
• Updated “QFN Package Dimensions” on page 146 (updated thermal characteristics)
F3
• Updated “Analog Input Characteristics (Commercial - CNZ)” on page 14 and “Analog Input Charac-
teristics (Automotive - DNZ)” on page 15 (corrected MICIN/LINEIN input impedance)
• Added “S/PDIF Input and Outputs” on page 143
• Updated “QFN Package Dimensions” on page 146 (corrected D2, E2, and L dimensions)
F4 • Changed CS4207-CNZ and CS4207-DNZ containers to “Tray” in Section 11 .
