16 DS880F4
CS4207
ADC DIGITAL FILTER CHARACTERISTICS
6. Response is clock dependent and will scale with Fs.
Parameter
(Note 6)
Min Typ Max Unit
Passband (Frequency Response) to -0.1 dB corner 0 - .4535 Fs
Passband Ripple -0.09 - 0.17 dB
Stopband 0.6 - - Fs
Stopband Attenuation 70 - - dB
Total Group Delay - 7.6/Fs - s
High-Pass Filter Characteristics
(48 kHz Fs)
Frequency Response -3.0 dB
-0.13 dB -
- 3.6
24.2
-
- Hz
Hz
Phase Deviation @ 20 Hz - 10 - Deg
Passband Ripple - - 0.17 dB
Filter Settling Time - 10
5
/Fs 0 s
