5.4 Bill of Materials
Figure 25. BOM (Page 1 of 2)
Item Designator Value Manufacturer Part Number Package Per Qty Assembly Notes
1 BR1 HD04 Diodes, Inc. RH04-T 4 pin Mini- Dip 1
2
C1 CAPACITOR PEN FILM, 0.1UF, 250V, RADIAL Epcos B32559C3104K alt C050-035X075 1
Alt part from digikey 565-3288-ND MFPN
KHD251E104M43A0B00
C23 CAP CER 0.1UF 250V 10% RADIAL TDK Corporation FK26X7R2E104K 5.50 x 3.50 1
C2 CAP CER 47PF 50V 5% NP0 0402 TDK Corporation C1005C0G1H151J C0402 1
5 C4 CAP CER 4700PF 630V 10% RADIAL TDK Corporation FK26X7R2J472K 5.50 x 3.50 1
6,8 C3, C5, C17 CAP CER 1UF 50V 20% X6S 0603 TDK Corporation C1608X6S1H105M C0603 3
9-10 C6 CAPACITOR ALUM ELEC, 22UF, 250V, RADIAL RUBYCON 250BXC22MEFC10X16 10X16 1 Leads should be Teflon tube isolated
11 C7, C15 CAP CER 0.022UF 1KV 10% X7R 1210 Murata Electronics North America GRM32DR73A223KW01L 1210 2 No Pop C15
12 C8 CAP ALUM 100UF 16V 20% RADIAL Nichicon RNE1C101MDS1PX E2.5-5 1
13 C9 CAP CER 100PF 50V 10% X7R 0603 TDK Corporation C1608X7R1H101K C0603 1
14 C10 CAP CER 10UF 10V X5R 0805 Taiyo Yuden LMK107BJ106MALTD C0603 1
C11 CAP ALUM 22UF 35V 20% RADIAL Nichicon UVZ1V220MDD E2.5-5 1
17 C12 CAP CER 4.7UF 25V X5R 0805 TDK Corporation C2012X5R1E475K C0805K 1
18 C13 CAP FILM 0.033UF 250VDC RADIAL Epcos B32529C3333K C050-035X075 1
19 C14 CAP CER 47PF 50V 5% NP0 0603 TDK Corporation C1608C0G1H470J C0603 1
C15 CAP ALUM 68UF 16V 20% RADIAL Panasonic – ECG EEU-FM1C680 E2.5-5 1
C16 CAP CER 47PF 50V 5% NP0 0402 TDK Corporation C1005C0G1H470J C0402 1
C18 CAP CER 10000PF 250V 20% RADIAL Murata Electronics North America DE2F3KY103MB3BM02 Radial - Disc 1 No Pop
22 C24 CAP CER 470PF 50V 10% X7R 0603 TDK Corporation C1608X7R1H471K C0603 1
23 C19 No Pop
24-26 D1, D6, D8, D10 DIODE SWITCH 75V 200MW SOD323 Diodes Inc 1N4148WS-7-F SOD-323 3
D7 DIODE SS SW 200MW 350V SOD-323 Diodes Inc BAV3004WS-7 SOD-322 1
27 D2 DIODE SCHOTTKY 40V 120MA SOD-323 NXP Semiconductors RB751V40,115 SOD-323 1
28 D3 DIODE SCHOTTKY 40V 0.3A SOT-23 STMicroelectronics BAT54SFILM SOT-23 1
29 D4 DIODE ULTRA FAST GPP 400V 1A SMA Diodes Inc US1G-13-F SMA 1 Leads should be Teflon tube isolated
30 D5 DIODE SCHOTTKY 1A 30V SMA Vishay/General Semiconductor SL13HE3/5AT SMA 1
31 D9 DIODE ZENER 5.1V 500MW SOD80C NXP Semiconductors BZV55-C5V1,115 SOD-80C 1
32 D15 DIODE SCHOTTKY 1A 90V SMA Vishay Semiconductors SS1H9-E3/61T SMA 1
33-34 FH1 FUSE PICO FAST 1.5A 125V AXIAL LittleFuse Inc 025101.5MRT1L 0309V 1
35
'L', 'N', 'W+', 'W-', 'R+', 'R-
'
CONN HEADER RT/A .100 1POS 15AU TE Connectivity 87233-1 8
Look for 'L', 'N', 'W+', 'W-', 'R+', 'R-' in
silk screen for designation. No Pop NTC+
and NTC -
40
J12, J13
34 Gauge Wire jumper from J12 to J13.
Wire should be have teflon isolation but
heat shrink tubing NOT REQUIRED
41
J7, J8
34 Gauge Wire jumper from J7 to J8. Wire
should be have teflon isolation but heat
shrink tubing NOT REQUIRED
J9, J14
34 Gauge Wire jumper from J7 to J8. Wire
should be have teflon isolation but heat
shrink tubing NOT REQUIRED
